Legacy compact desktop next-generation firewall built on Fortinet's purpose-built SoC security processor, with 2.5 Gbps firewall throughput, 1.8 million concurrent sessions, seven GE RJ45 ports and a 32 GB onboard SSD in a fanless form factor for small offices and branches. The FortiGate 51E hardware is no longer stocked — FortiGuard and FortiCare renewals are still available below, and the FortiGate 51G is the direct, currently-shipping replacement.
The FortiGate 51E hardware is legacy and no longer stocked. These FortiGuard and FortiCare renewals keep an installed unit licensed and supported. Licensing is delivered electronically worldwide.
| Bundle includes | Enterprise | UTP | ATP |
|---|---|---|---|
| Firewall hardware | ✓ | ✓ | ✓ |
| IPS, malicious/botnet URL | ✓ | ✓ | ✓ |
| Anti-malware (AMP, sandbox, CDR) | ✓ | ✓ | ✓ |
| URL, DNS & video filtering | ✓ | ✓ | — |
| Anti-spam | ✓ | ✓ | — |
| AI-based inline malware prevention | ✓ | — | — |
| Data loss prevention (DLP) | ✓ | — | — |
| Attack surface security | ✓ | — | — |
| FortiCare Premium support | ✓ | ✓ | ✓ |
Item | SKU | Price | ||
|---|---|---|---|---|
 | FC-10-0051E-810-02-12 | List price:CAD$1,090.08 Our Price:CAD$879.09 | ||
 | FC-10-0051E-950-02-12 | List price:CAD$898.88 Our Price:CAD$724.90 | ||
 | FC-10-0051E-928-02-12 | List price:CAD$577.85 Our Price:CAD$466.01 |
| Bundle includes | Enterprise | UTP | ATP |
|---|---|---|---|
| Firewall hardware | ✓ | ✓ | ✓ |
| IPS, malicious/botnet URL | ✓ | ✓ | ✓ |
| Anti-malware (AMP, sandbox, CDR) | ✓ | ✓ | ✓ |
| URL, DNS & video filtering | ✓ | ✓ | — |
| Anti-spam | ✓ | ✓ | — |
| AI-based inline malware prevention | ✓ | — | — |
| Data loss prevention (DLP) | ✓ | — | — |
| Attack surface security | ✓ | — | — |
| FortiCare Premium support | ✓ | ✓ | ✓ |
Item | SKU | Price | ||
|---|---|---|---|---|
 | FC-10-0051E-100-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 | ||
| | FC-10-0051E-108-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 | ||
| | FC-10-0051E-112-02-12 | List price:CAD$385.24 Our Price:CAD$310.67 | ||
| | FC-10-0051E-159-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 | ||
| | FC-10-0051E-175-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 |
The FortiGate 51E is a legacy compact desktop next-generation firewall from Fortinet's 50E series. Built on a purpose-built SoC security processor, it delivers 2.5 Gbps of firewall throughput, 220 Mbps NGFW, 160 Mbps of threat protection and 1,800,000 concurrent sessions over seven GE RJ45 ports (two WAN and five internal/switch), with a 32 GB onboard SSD for local logging and reporting. The 51E reached end of order in 2022 (end of support 2027), so the hardware is no longer stocked; you can still renew its FortiGuard security services and FortiCare support to keep an installed unit protected, using the renewal bundles below.
When you are ready to replace it, the currently-shipping FortiGate 51G is the direct successor — a full-generation jump in firewall throughput, threat protection and SD-WAN performance in the same compact desktop class, also with an onboard SSD — and the FortiGate 70G steps up further with 10 Gbps firewall throughput and higher session capacity. See the upgrade path comparison below.
A quick guide to keeping your existing unit protected, or moving to a current FortiGate.
| Firewall throughput (1518 / 512 / 64 byte, UDP) | 2.5 / 2.5 / 2.5 Gbps |
| Firewall latency (64 byte, UDP) | 180 µs |
| Firewall throughput (packets/sec) | 375 Kpps |
| Concurrent sessions (TCP) | 1,800,000 |
| New sessions/second (TCP) | 21,000 |
| Firewall policies | 5,000 |
| IPS throughput (Enterprise mix) | 350 Mbps |
| NGFW throughput (Enterprise mix) | 220 Mbps |
| Threat protection throughput (Enterprise mix) | 160 Mbps |
| IPsec VPN throughput (512 byte) | 90 Mbps |
| Gateway-to-gateway IPsec VPN tunnels | 200 |
| Client-to-gateway IPsec VPN tunnels | 250 |
| SSL-VPN throughput | 100 Mbps |
| Concurrent SSL-VPN users (tunnel mode, rec. max) | 200 |
| SSL inspection throughput (IPS, avg. HTTPS) | 150 Mbps |
| SSL inspection CPS (IPS, avg. HTTPS) | 140 |
| SSL inspection concurrent sessions | 75,000 |
| Application control throughput (HTTP 64K) | 450 Mbps |
| CAPWAP throughput (HTTP 64K) | 1.2 Gbps |
| Virtual domains (default / max) | 5 / 5 |
| Managed FortiAPs (total / tunnel) | 10 / 5 |
| High availability | Active-Active, Active-Passive |
| Hardware acceleration | Fortinet SPU (SoC) |
| Interfaces | 7x GE RJ45 ports (2x WAN, 5x internal/switch), 1x USB, 1x console (RJ45) |
| Onboard storage | 1x 32 GB SSD |
| Weight | 2.0 lbs (0.91 kg) |
| Form factor | Desktop, fanless |
| Dimensions (H x W x L) | 1.44 x 8.52 x 5.5 in (36.5 x 216 x 140 mm) |
| Power input | 100-240V AC, 50/60 Hz (external DC power adapter) |
| Operating temperature | 32°F to 104°F (0°C to 40°C) |
| Storage temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 10% to 90% non-condensing |
| Compliance | FCC Part 15 Class B, RCM, VCCI, CE, UL/cUL, CB |
| Certifications | ICSA Labs (Firewall, IPsec, IPS, Antivirus, SSL-VPN) |
| Power consumption (avg / max) | 15 W / 18 W |
| Heat dissipation | 62 BTU/h |
| Noise level | 0 dBA (fanless) |
| Power supply | External DC adapter |
| Product lifecycle | Legacy — end of order 2022, end of support 2027; renewals available; upgrade path: FortiGate 51G |
Source: official Fortinet FortiGate/FortiWiFi 50E Series datasheet (FORTIGATE 51E column, FGFWF-50E-DAT-R22-201906). The 50E series shares system performance; the 51E adds a 1x 32 GB onboard SSD over the base 50E. The datasheet button links to the FortiGate/FortiWiFi 50E series datasheet hosted on DataCenter360.ca.
Download the FortiGate 50E datasheetSame 50E-series platform and 2.5 Gbps firewall performance across the line. The two models differ only by onboard storage — the 50E has none, the 51E adds a 1x 32 GB SSD.
| Model | Ports | Onboard storage | |
|---|---|---|---|
| FortiGate 50E | 7x GE RJ45 (2x WAN, 5x switch) | — | View → |
| FortiGate 51E | 7x GE RJ45 (2x WAN, 5x switch) | 1x 32 GB SSD | Viewing |
The FortiGate 51E is legacy. The FortiGate 51G is the direct, currently-shipping replacement with a full-generation jump in firewall throughput, threat protection and SD-WAN performance, also with an onboard SSD; the FortiGate 70G steps up further with 10 Gbps firewall throughput and higher session capacity. Same FortiOS and FortiGuard services across the range.
Every licensing option still available for the FG-51E: FortiGuard + FortiCare renewal bundles, individual FortiGuard services, FortiCare support, and FortiGate Cloud management. Licensing is delivered electronically worldwide.
| Bundle includes | Enterprise | UTP | ATP |
|---|---|---|---|
| Firewall hardware | ✓ | ✓ | ✓ |
| IPS, malicious/botnet URL | ✓ | ✓ | ✓ |
| Anti-malware (AMP, sandbox, CDR) | ✓ | ✓ | ✓ |
| URL, DNS & video filtering | ✓ | ✓ | — |
| Anti-spam | ✓ | ✓ | — |
| AI-based inline malware prevention | ✓ | — | — |
| Data loss prevention (DLP) | ✓ | — | — |
| Attack surface security | ✓ | — | — |
| FortiCare Premium support | ✓ | ✓ | ✓ |
Item | SKU | Price | ||
|---|---|---|---|---|
| | FC-10-0051E-810-02-12 | List price:CAD$1,090.08 Our Price:CAD$879.09 | ||
| | FC-10-0051E-950-02-12 | List price:CAD$898.88 Our Price:CAD$724.90 | ||
| | FC-10-0051E-928-02-12 | List price:CAD$577.85 Our Price:CAD$466.01 |
| Bundle includes | Enterprise | UTP | ATP |
|---|---|---|---|
| Firewall hardware | ✓ | ✓ | ✓ |
| IPS, malicious/botnet URL | ✓ | ✓ | ✓ |
| Anti-malware (AMP, sandbox, CDR) | ✓ | ✓ | ✓ |
| URL, DNS & video filtering | ✓ | ✓ | — |
| Anti-spam | ✓ | ✓ | — |
| AI-based inline malware prevention | ✓ | — | — |
| Data loss prevention (DLP) | ✓ | — | — |
| Attack surface security | ✓ | — | — |
| FortiCare Premium support | ✓ | ✓ | ✓ |
Item | SKU | Price | ||
|---|---|---|---|---|
| | FC-10-0051E-100-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 | ||
| | FC-10-0051E-108-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 | ||
| | FC-10-0051E-112-02-12 | List price:CAD$385.24 Our Price:CAD$310.67 | ||
| | FC-10-0051E-159-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 | ||
| | FC-10-0051E-175-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 |
Item | SKU | Price | ||
|---|---|---|---|---|
 | FC-10-0051E-314-02-12 | List price:CAD$192.62 Our Price:CAD$180.58 | ||
| | FC-10-0051E-247-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 | ||
| | FC-10-0051E-284-02-12 | List price:CAD$321.03 Our Price:CAD$258.89 | ||
| | FC-10-0051E-204-02-12 | List price:CAD$64.21 Our Price:CAD$60.20 |
Item | SKU | Price | ||
|---|---|---|---|---|
 | FC-10-0051E-131-02-12 | List price:CAD$205.46 Our Price:CAD$165.69 | ||
| | FC-10-0051E-288-02-12 | List price:CAD$256.82 Our Price:CAD$207.11 | ||
| | FC-10-0051E-585-02-12 | List price:CAD$385.24 Our Price:CAD$310.67 | ||
| | FC-10-0051E-464-02-12 | List price:CAD$737.66 Our Price:CAD$594.89 | ||
 | FC-10-0051E-189-02-12 | List price:CAD$71.34 Our Price:CAD$66.89 |
The FortiGate 51E is a fanless desktop unit that ships with an external power adapter; its seven GE RJ45 ports need no transceivers. See all Fortinet accessories for power and mounting options.
The FortiGate 51E (FG-51E) is legacy — end of order was 2022 and the hardware is no longer stocked. You can still renew FortiGuard security services and FortiCare support for an installed unit (end of support is 2027), and we can quote the current FortiGate 51G as a direct replacement.
The FortiGate 51G is the direct, currently-shipping replacement — a full-generation jump in firewall throughput and threat protection in the same compact desktop class, also with an onboard SSD. For more throughput and sessions, step up to the FortiGate 70G.
Yes, while the model is in its renewal window (end of support is 2027). Choose a FortiGuard + FortiCare renewal bundle (Enterprise, UTP or ATP) above, or renew individual FortiGuard services and FortiCare support. Licensing is delivered electronically worldwide.
The 51E delivers 2.5 Gbps firewall throughput, 350 Mbps IPS, 220 Mbps NGFW, 160 Mbps threat protection and 90 Mbps IPsec VPN, with 1,800,000 concurrent sessions and 21,000 new sessions per second, accelerated by Fortinet’s purpose-built SoC security processor, over seven GE RJ45 ports (two WAN and five internal/switch) with a 32 GB onboard SSD in a fanless desktop form factor.
The FortiGate 51E adds a 1x 32 GB onboard SSD to the base 50E for local logging and reporting; ports and security performance are otherwise identical to the 50E.
