Fortinet FortiAP 222KL Outdoor Wi-Fi 7 IoT Access Point (FAP-222KL-A)

Some outdoor sites are less about peak Wi-Fi speed and more about connecting things in places without easy backhaul. The FortiAP 222KL (FAP-222KL-A) is built for exactly that: a ruggedized outdoor Wi-Fi 7 access point that folds LoRaWAN and an LTE Cat-4 modem into the same enclosure. Two 2×2 Wi-Fi radios on 2.4 and 5 GHz cover users and devices, while the LoRaWAN gateway reaches low-power IoT sensors across long distances and the LTE radio provides cellular backhaul where running fibre is impractical.

What’s in the box

The AP, wall and pole mounting brackets, a grounding cable, and 802.3bt PoE. The five antennas are external N-type connections (Wi-Fi, LoRaWAN, LTE, and GNSS), so coverage and IoT reach can be tuned per site.

Hardware Specifications

Where it earns its place

The 222KL is an IoT-first outdoor AP. The integrated LoRaWAN gateway collects data from long-range, low-power sensors, smart-city meters, agricultural probes, asset trackers, that would otherwise need a separate gateway. The LTE Cat-4 modem gives the unit a cellular uplink for remote yards, parking structures, and temporary sites where wired backhaul is not available. On the Wi-Fi side, two Wi-Fi 7 radios still deliver up to 4.324 Gbps on 5 GHz for the people and devices on site. GNSS keeps the AP location-aware for fleet and asset use cases.

Powering it

The 222KL uses 802.3bt PoE, which ships with the unit, and the second RJ45 can act as PSE or PD for chaining a downstream device. Plan a bt-capable switch port or the GPI-145 injector for the full feature set including the LTE and LoRaWAN radios.

Management and licensing

The Wi-Fi side is managed by a FortiGate or FortiEdge Cloud with no per-AP operating license. FortiCare Premium support for the AP (FC-10-F22KL- prefix) is optional and sold separately. LTE service requires a carrier SIM, and LTE module availability is subject to country and region.

Who runs it

Smart-city, utility, campus-exterior, agricultural, and transport deployments that need to connect sensors and provide Wi-Fi where backhaul is the hard part. If the priority is maximum outdoor Wi-Fi throughput rather than IoT and cellular backhaul, the FortiAP 244K is the better fit.

Moving up

The FortiAP 244K steps up to four radios with 6 GHz support and a 10 Gbps SFP+ uplink for outdoor sites that need raw wireless capacity over IoT integration.

Buying from DataCenter360.ca

DataCenter360.ca supplies the FAP-222KL-A in Canada as an authorized Fortinet Select Partner, factory-sealed with full Canadian warranty and free shipping in 0 to 1 business days. LoRaWAN and LTE behaviour depends on your region and carrier, so tell us the deployment and we will confirm the module options before you order.
