Ruggedized outdoor Wi-Fi 7 access point and LoRaWAN gateway in one IP67 enclosure — two 2x2 Wi-Fi radios on 2.4 and 5 GHz, an integrated LoRaWAN radio for long-range IoT sensors, LTE Cat 4 backhaul and multi-constellation GNSS. Five external N-type antennas, 802.3bt PoE in and 802.3af PoE out, rated to -40°C, 165 mph wind, Class 1 Division 2 and ATEX Zone 2. Managed by your FortiGate, FortiEdge Cloud or FortiSASE.
The configurations most customers buy: the access point on its own, or with FortiCare Premium support. The complete catalog is further down.
| Configuration | Price & action |
|---|---|
| FortiAP 222KL outdoor Wi-Fi 7 access point with LoRaWAN gateway, LTE backhaul and GNSS. License not included. | View productFAP-222KL-A Original price was: CAD$3,842.18.CAD$2,702.19Current price is: CAD$2,702.19.Add to cart |
Brand-new, sealed · ships same / next business day · price shown live in your selected currency.
| Support | 1 Year | 3 Years | 5 Years |
|---|---|---|---|
| FortiCare Essential Renewal only — not sold with initial hardware purchase. | View productFC-10-F22KL-314-02-12 Original price was: CAD$166.33.CAD$155.93Current price is: CAD$155.93.Add to cart | View productFC-10-F22KL-314-02-36 Original price was: CAD$498.98.CAD$415.82Current price is: CAD$415.82.Add to cart | View productFC-10-F22KL-314-02-60 Original price was: CAD$831.64.CAD$693.03Current price is: CAD$693.03.Add to cart |
| FortiCare Premium 24×7 TAC, advanced hardware replacement & firmware updates. Most-purchased tier for new APs. | View productFC-10-F22KL-247-02-12 Original price was: CAD$332.66.CAD$277.21Current price is: CAD$277.21.Add to cart | View productFC-10-F22KL-247-02-36 Original price was: CAD$997.97.CAD$831.64Current price is: CAD$831.64.Add to cart | View productFC-10-F22KL-247-02-60 Original price was: CAD$1,663.28.CAD$1,355.93Current price is: CAD$1,355.93.Add to cart |
FortiCare and subscriptions delivered electronically worldwide · prices shown live in your selected currency · add-to-cart enabled when in stock.
The FortiAP 222KL is the only FortiAP that combines enterprise Wi-Fi with a LoRaWAN IoT gateway in a single outdoor enclosure. Two Wi-Fi 7 radios deliver 2x2 MU-MIMO on the 2.4 and 5 GHz bands — up to 688 Mbps and 2.88 Gbps respectively — while a dedicated LoRaWAN radio (902-928 MHz in North America, 8 uplink channels, SF7-SF12, 26 dBm transmit and -139 dBm receive sensitivity) reaches battery-powered sensors kilometres away that Wi-Fi cannot economically cover. That combination is what makes it a site-in-a-box for utilities, agriculture, ports, mining, oil and gas, campuses and smart-city deployments.
Where there is no fibre or copper to the pole, an integrated LTE Cat 4 modem with eSIM provides 150 / 50 Mbps backhaul, and multi-constellation GNSS (GPS, GLONASS, BeiDou, Galileo, QZSS and SBAS) gives each unit an accurate position and timing reference. A second RJ45 port acts as 802.3af power sourcing equipment, so the AP can power a camera or a sensor bridge downstream instead of requiring its own switch at the pole. Five external N-type antenna connections let you match gain and pattern to the site rather than accept a fixed internal array.
Construction is built for the worst of the site: IP67 sealing, -40°F to 158°F (-40°C to 70°C) operating range, 165 mph (266 km/h) wind rating, 3,000 m altitude and Class 1 Division 2 / ATEX Zone 2 hazardous-location compliance. A Trusted Platform Module anchors hardware identity, and the AP is managed by any FortiGate's built-in WLAN controller, by FortiEdge Cloud or through FortiSASE — no separate wireless controller and no per-AP management licence. Note that the LTE module's availability depends on the country of use, and it is not supported in the early release firmware.
Ask AI about the FAP-222KLA quick guide to choosing the right outdoor FortiAP access point.
| Type | Outdoor ruggedized access point, Wi-Fi 7 (802.11be); Wi-Fi 7 certification in progress |
| Radios | 2 Wi-Fi (2.4 GHz + 5 GHz) + 1 LoRaWAN + 1 LTE Cat 4 + 1 GNSS |
| Spatial streams | 2x2 MU-MIMO per Wi-Fi radio (UL & DL), OFDMA, BSS coloring, Enhanced TWT |
| Wi-Fi data rate | Up to 688 Mbps (2.4 GHz) and up to 4.324 Gbps (5 GHz at 240 MHz); about 2.88 Gbps on a 160 MHz channel |
| Channel width | 20 / 40 MHz (2.4 GHz); 20 / 40 / 80 / 160 / 240 MHz (5 GHz) |
| 6 GHz band | Not supported (dual-band 2.4 / 5 GHz) |
| Antennas | 5 external N-type: 2 dual-band Wi-Fi (5 dBi @ 2.4 GHz / 6.5 dBi @ 5 GHz), 1 LoRaWAN omni (4 dBi), 1 LTE (2.7 dBi), 1 GNSS patch directional (4 dBi) |
| LoRaWAN (North America) | 902-928 MHz · 8x 125 kHz uplink (902.3-914.9 MHz), 1x 500 kHz downlink · SF7-SF12 · 26 dBm TX · -139 dBm RX |
| LTE backhaul | Cat 4 eSIM, 150 Mbps down / 50 Mbps up · 4G, 3G and 2G bands worldwide · availability subject to country of use |
| GNSS | GPS L1 C/A, GLONASS L1, BeiDou, Galileo E1, plus QZSS and SBAS ranging; -165 dBm tracking, -148 dBm acquisition |
| Ethernet | Port 1: RJ45 multigigabit (100M / 1G / 2.5G) with 802.3bt PoE-IN · Port 2: RJ45 (10M / 100M / 1G) with 802.3af PoE-OUT (PSE) · Console: RJ45 RS-232 |
| Power over Ethernet | 802.3bt PoE injector included; passive PoE supported; PSE enabled on port 2 |
| Power consumption | 26 W maximum |
| Client capacity | Up to 512 clients per radio (2 Wi-Fi radios) |
| SSIDs | Up to 8 per client-serving radio |
| Security | WPA3 / WPA2 / WPA with 802.1X or PSK, WEP, captive portal, MAC allow / block list, background rogue scan, WIPS / WIDS, packet sniffer, spectrum analyzer, TPM |
| UTP capable | No |
| Management | FortiGate built-in WLAN controller, FortiEdge Cloud or FortiSASE |
| CPU / memory | Quad-core ARM Cortex-A53 1.5 GHz / 2 GB |
| Mounting | Wall and pole mounting brackets included; 802.3bt PoE and grounding cable in the box |
| Dimensions / weight | 8.66 x 8.66 x 2.36 in (220 x 220 x 60 mm) · 5.95 lb (2.7 kg) |
| Environmental | IP67 · -40°F to 158°F (-40°C to 70°C) · 5-90% non-condensing · 165 mph (266 km/h) wind · 3,000 m altitude |
| Regulatory | FCC / ISED, CE, Class 1 Division 2, ATEX Zone 2 · MTBF over 10 years |
| Warranty | Limited Lifetime Warranty |
Source: official Fortinet FortiAP Series datasheet (FAP-222KL columns). LoRaWAN channel plan shown for North America; frequency, power and LTE band availability vary by regional regulation.
Download the full datasheet
Every Fortinet purchase from DataCenter360.ca is backed by hands-on services across the full lifecycle — from rollout to round-the-clock protection.
Outdoor and ruggedized FortiAP models. They differ by Wi-Fi generation, spatial streams, antenna type and what else is built in. The 222KL is the only one that carries a LoRaWAN IoT gateway, LTE backhaul and GNSS alongside its Wi-Fi radios.
The 222KL trades raw Wi-Fi throughput for IoT and cellular reach. Choose the 244K when you need 6 GHz and a 10 Gigabit uplink outdoors, or the 234G for a lower-cost Wi-Fi 6E outdoor unit.
Every available SKU for the FAP-222KL: access point hardware (Americas region), FortiCare support tiers, FortiSASE cloud management and RMA services. In stock; licensing delivered electronically worldwide.
| Configuration | Price & action |
|---|---|
| FortiAP 222KL outdoor Wi-Fi 7 access point with LoRaWAN gateway, LTE backhaul and GNSS. License not included. | View productFAP-222KL-A Original price was: CAD$3,842.18.CAD$2,702.19Current price is: CAD$2,702.19.Add to cart |
Brand-new, sealed · ships same / next business day · price shown live in your selected currency.
| Support | 1 Year | 3 Years | 5 Years |
|---|---|---|---|
| FortiCare Essential Renewal only — not sold with initial hardware purchase. | View productFC-10-F22KL-314-02-12 Original price was: CAD$166.33.CAD$155.93Current price is: CAD$155.93.Add to cart | View productFC-10-F22KL-314-02-36 Original price was: CAD$498.98.CAD$415.82Current price is: CAD$415.82.Add to cart | View productFC-10-F22KL-314-02-60 Original price was: CAD$831.64.CAD$693.03Current price is: CAD$693.03.Add to cart |
| FortiCare Premium 24×7 TAC, advanced hardware replacement & firmware updates. Most-purchased tier for new APs. | View productFC-10-F22KL-247-02-12 Original price was: CAD$332.66.CAD$277.21Current price is: CAD$277.21.Add to cart | View productFC-10-F22KL-247-02-36 Original price was: CAD$997.97.CAD$831.64Current price is: CAD$831.64.Add to cart | View productFC-10-F22KL-247-02-60 Original price was: CAD$1,663.28.CAD$1,355.93Current price is: CAD$1,355.93.Add to cart |
| FortiCare Elite Priority TAC queue, quarterly review & dedicated team. | View productFC-10-F22KL-284-02-12 Original price was: CAD$498.98.CAD$415.82Current price is: CAD$415.82.Add to cart | View productFC-10-F22KL-284-02-36 Original price was: CAD$1,496.95.CAD$1,220.33Current price is: CAD$1,220.33.Add to cart | View productFC-10-F22KL-284-02-60 Original price was: CAD$2,494.92.CAD$2,033.90Current price is: CAD$2,033.90.Add to cart |
| FortiCare Premium → Elite Upgrade Step an existing FortiCare Premium contract up to Elite mid-term. | View productFC-10-F22KL-204-02-12 Original price was: CAD$166.33.CAD$155.93Current price is: CAD$155.93.Add to cart | View productFC-10-F22KL-204-02-36 Original price was: CAD$498.98.CAD$415.82Current price is: CAD$415.82.Add to cart | View productFC-10-F22KL-204-02-60 Original price was: CAD$831.64.CAD$693.03Current price is: CAD$693.03.Add to cart |
| Subscription | 1 Year | 3 Years | 5 Years |
|---|---|---|---|
| FortiSASE for cloud-managed FortiAP Cloud management + secure SD-WAN / SASE for the access point. | View productFC-10-F22KL-595-02-12 Original price was: CAD$1,164.30.CAD$970.25Current price is: CAD$970.25.Add to cart | View productFC-10-F22KL-595-02-36 Original price was: CAD$3,492.89.CAD$2,847.47Current price is: CAD$2,847.47.Add to cart | View productFC-10-F22KL-595-02-60 Original price was: CAD$5,821.48.CAD$4,644.79Current price is: CAD$4,644.79.Add to cart |
FortiCare and subscriptions delivered electronically worldwide · prices shown live in your selected currency · add-to-cart enabled when in stock.
| RMA | 1 Year | 3 Years | 5 Years |
|---|---|---|---|
| Next-Calendar-Day RMA Replacement unit dispatched the next calendar day. | View productFC-10-F22KL-210-02-12 Original price was: CAD$346.52.CAD$288.76Current price is: CAD$288.76.Add to cart | View productFC-10-F22KL-210-02-36 Original price was: CAD$1,039.55.CAD$866.29Current price is: CAD$866.29.Add to cart | View productFC-10-F22KL-210-02-60 Original price was: CAD$1,732.58.CAD$1,412.43Current price is: CAD$1,412.43.Add to cart |
| 4-Hour Delivery RMA Advance replacement delivered within 4 hours. | View productFC-10-F22KL-211-02-12 Original price was: CAD$485.12.CAD$404.27Current price is: CAD$404.27.Add to cart | View productFC-10-F22KL-211-02-36 Original price was: CAD$1,455.37.CAD$1,186.45Current price is: CAD$1,186.45.Add to cart | View productFC-10-F22KL-211-02-60 Original price was: CAD$2,425.62.CAD$1,977.40Current price is: CAD$1,977.40.Add to cart |
| 4-Hour Delivery + Onsite RMA 4-hour part plus a Fortinet onsite engineer dispatched. | View productFC-10-F22KL-212-02-12 Original price was: CAD$731.84.CAD$609.87Current price is: CAD$609.87.Add to cart | View productFC-10-F22KL-212-02-36 Original price was: CAD$2,195.53.CAD$1,789.83Current price is: CAD$1,789.83.Add to cart | View productFC-10-F22KL-212-02-60 Original price was: CAD$3,659.22.CAD$2,983.05Current price is: CAD$2,983.05.Add to cart |
| Secure RMA Keep your failed unit — no return of the defective AP required. | View productFC-10-F22KL-301-02-12 Original price was: CAD$249.49.CAD$233.90Current price is: CAD$233.90.Add to cart | View productFC-10-F22KL-301-02-36 Original price was: CAD$748.48.CAD$623.73Current price is: CAD$623.73.Add to cart | View productFC-10-F22KL-301-02-60 Original price was: CAD$1,247.46.CAD$1,039.55Current price is: CAD$1,039.55.Add to cart |
FortiCare and subscriptions delivered electronically worldwide · prices shown live in your selected currency · add-to-cart enabled when in stock.
Power and protect the FortiAP 222KL — the 802.3bt injector, mounting brackets and grounding cable ship in the box.
The 222KL ships with its 802.3bt PoE injector, wall and pole mounting brackets and a grounding cable. On outdoor masts, fit the FAP-LGHT-ARST-1PACK coaxial lightning arrestors in line with the external antennas — this pack is made specifically for the 222KL.
The FortiAP 222KL is a current-generation Wi-Fi 7 outdoor access point, actively sold and fully supported. It is not on an end-of-order or end-of-support schedule.
It is the only FortiAP that pairs enterprise Wi-Fi with a built-in LoRaWAN gateway. Alongside its two 2×2 Wi-Fi 7 radios it carries a LoRaWAN radio for long-range low-power IoT sensors, an LTE Cat 4 modem for backhaul where there is no wired connection, and multi-constellation GNSS. Other outdoor models such as the 244K and 432G give you more Wi-Fi throughput but no LoRaWAN or LTE.
In North America it operates on 902-928 MHz with eight 125 kHz uplink channels (902.3-914.9 MHz) and one 500 kHz downlink channel, spreading factors SF7 through SF12, 26 dBm transmit power and -139 dBm receive sensitivity. That reach lets a single gateway cover sensors spread across a site or several kilometres of open ground.
No. The 222KL is a dual-band Wi-Fi 7 access point covering 2.4 and 5 GHz, reaching up to 688 Mbps and 2.88 Gbps respectively. If you need 6 GHz outdoors, the FortiAP 244K adds a 6 GHz radio, a dedicated scanning radio and a 10 Gigabit SFP+ uplink.
Port 1 is a multigigabit RJ45 (100M / 1G / 2.5G) with 802.3bt PoE input, and the 802.3bt injector ships in the box. Port 2 is a 1 Gigabit RJ45 that acts as 802.3af power sourcing equipment, so the AP can power a downstream camera or sensor bridge. Maximum draw is 26 W. Where no cable can reach, the LTE Cat 4 modem provides 150 / 50 Mbps backhaul, subject to your country of use.
Yes. It is rated Class 1 Division 2 and ATEX Zone 2, sealed to IP67, operates from -40°C to 70°C, withstands 165 mph (266 km/h) wind and is rated to 3,000 m altitude — suitable for fuel, chemical, mining and process environments. Use the FAP-LGHT-ARST-1PACK coaxial lightning arrestors on mast-mounted antennas.
The FAP-222KL-A (Americas) is in stock and usually dispatched the same or next business day. FortiCare support and subscriptions are delivered electronically, worldwide. DataCenter360.ca is an authorized Fortinet Select Partner.
